Chapter
Introduction
Chapter 13 ACL
This module is used to configure match rules and process
policies of packets to filter packets in order to control the
access of the illegal users to the network. Here mainly
introduces:
Time-Range: Configure the effective time for ACL rules.
ACL Config: ACL rules.
Policy Config: Configure operation policies.
ACL Binding: Bind the ACL to a port/VLAN to take its effect
on a specific port/VLAN.
Policy Binding: Bind the policy to a port/VLAN to take its
effect on a specific port/VLAN.
Chapter 14 Network Security
This module is used to configure the protection measures for
the network security. Here mainly introduces:
IP-MAC Binding: Bind the IP address, MAC address, VLAN
ID and the connected Port number of the Host together.
IPv6-MAC Binding: Bind the IPv6 address, MAC address,
VLAN ID and the connected Port number of the Host
together.
DHCP Snooping: DHCP Snooping functions to monitor the
process of the Host obtaining the IP address from DHCP
server, and record the IP address, MAC address, VLAN and
the connected Port number of the Host for automatic
binding.
DHCPv6 Snooping: DHCPv6 Snooping functions to monitor
the process of the Host obtaining the IPv6 address from
DHCPv6 server, and record the IPv6 address, MAC
address, VLAN and the connected Port number of the Host
for automatic binding.
ARP Inspection: Configure ARP inspection feature to
prevent the network from ARP attacks.
ND Detection: Configure ND detection feature to prevent
the network from ND attacks.
IP Source Guard: Configure IP source guard feature to filter
IP packets in the LAN.
DoS Defend: Configure DoS defend feature to prevent DoS
attack.
802.1X: Configure common access control mechanism for
LAN ports to solve mainly authentication and security
problems.
PPPoE: Configure the PPPoE ID insertion feature.
AAA: Configure the authentication, authorization and
accounting features.
