PANEL DESCRIPTION
1
yS/RF INDICATORS
➥ Shows the relative signal strength while receiving sig-
nals. (p. 13)
➥ Shows the output power level while transmitting. (p. 15)
uSKIP INDICATOR (p. 41)
Appears when the displayed memory channel is specified
as a skip channel.
iMEMORY INDICATOR (p. 24)
Appears when memory mode is selected.
oMEMORY CHANNEL NUMBER INDICATORS
➥ Shows the selected memory channel number. (p. 24)
➥ “C” appears when the call channel is selected. (p. 35)
!0PRIORITY WATCH INDICATOR (p. 44)
Appears while the priority watch is activated; blinks while
the watch is paused.
!1LOCK INDICATOR (p. 12)
Appears when the lock function is activated.
!2TONE INDICATORS
➥ “” appears while the subaudible tone encoder is in
use. (p. 17)
➥ “” appears while the tone
(CTCSS) squelch function is
in use. (p. 48)
➥ “” appears while the tone
(DTCS) squelch function is
in use. (p. 48)
➥ “” appears with the “” or “” indicator while the
pocket beep function
(CTCSS or DTCS) is in use. (p. 48)
!3DUPLEX INDICATORS (p. 17)
“+” appears when plus duplex, “–” appears when minus
duplex operation is selected.
!4AUTO POWER-OFF INDICATOR (p. 64)
Appears while the auto power-off function is in use.
!5NARROW MODE INDICATOR (p. 61)
Appears when the narrow mode is selected.
Narrow mode is available with some USA versions only.
