Icom IC-V8000 [40/88] I memory clearing
![Icom IC-V8000 [40/88] I memory clearing](/views2/1074121/page40/bg28.png)
29
5 MEMORY OPERATION
[EXAMPLE]: Clearing memory channel 20.
Push to select VFO. Rotate for selecting memory channel.Push momentarily.
V/MHz
SCAN
S.MW
MW
Push any switch, except .Push momentarily, then push again for 1 sec.
S.MW
MW
S.MW
MW
S.MW
MW
Beep
Beep
Beep
“
“
“
“
“
■ Memory clearing
Contents of programmed memories can be cleared (blanked),
if desired.
q Push [V/MHz(SCAN)] to select VFO mode.
w Push [MW(S.MW)] momentarily.
•“M” indicator and the memory channel number blink.
e Rotate the tuning dial to select the memory channel to be
cleared.
• Memory channels not yet programmed are blank.
r Push [MW(S.MW)] momentarily, then push [MW(S.MW)]
again for 1 sec.
☞ This operation must be performed within 1.5 sec.
• 3 beeps sound, then the frequency is cleared.
•“M” indicator blinks continuously.
• When clearing the call channel, the current VFO conditions are
re-programmed into the call channel automatically.
t Push any switch, except [MW(S.MW)], to return to VFO
mode.
☞NOTE: Be careful!— the contents of cleared memories
CANNOT be recalled.
