■ Specifications
GENERAL
• Frequency coverage : (unit: MHz)
USA Tx: 144–148/Rx: 136–174*
Asia, CSA Tx: 144–148/Rx: 136–174*
(Central South America)
Australia Tx/Rx: 144–148
Taiwan, Korea Tx/Rx: 144–146
*Guaranteed: 144–148 MHz range only.
• Type of emission : FM
• Number of memory channels : 207 (incl. 6 scan edges and 1 call)
• Frequency resolution : 5, 10, 12.5, 15, 20, 25, 30, 50 kHz
• Operating temperature range : –10°C to +60°C; +14˚F to +140˚F
• Frequency stability : ±10 ppm
(–10°C to +60°C)
• Power supply requirement : 13.8 V DC ±15%
• Current drain (at 13.8 V DC: approx.):
Transmit at 75 W 15 A
Receive standby 0.3 A typical
max. audio 1.0 A
• Antenna connector : SO-239 (50 Ω)
• Dimensions (proj. not included) : 150(W) × 50(H) × 150(D) mm
5
29
⁄32(W)×2(H)×5
29
⁄32(D) in
• Weight (approx.) : 1.1 kg; 2 lb 7 oz
TRANSMITTER
• Modulation system : Variable reactance frequency mod.
• Output power : 75/25/10/5 W* (approx.)
*24/10/5 W only for the Taiwan version.
• Max. frequency deviation : ±5.0 kHz (wide)/±2.5 kHz (narrow)
†
• Spurious emissions : Less than –60 dB
• Microphone connector : 8-pin modular (600 Ω)
RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st: 21.7 MHz, 2nd: 450 kHz
• Sensitivity (at 12 dB SINAD) : 0.15 µV typical
• Squelch sensitivity (threshold) : 0.08 µV typical
• Selectivity (typical) : 75 dB (wide)/60 dB (narrow)
†
• Spurious and image rejection : 75 dB typical
•
AF output power (at 13.8 V DC)
: More than 2.0 W at 10% distortion with
an 8 Ω load
• Ext. speaker connector : 3-conductor 3.5 (d) mm (
1
⁄8″)/8 Ω
†
Some versions only.
All stated specifications are subject to change without notice or obligation.
■ Options
UT-108
DTMF DECODER UNIT
HM-95/HM-118TAN/TN
DTMF MICROPHONES
HM-118N
HAND MICROPHONE
HM-133V
REMOTE
-
CONTROL MICROPHONE
SP-10
EXTERNAL SPEAKER
OPC-440/OPC-647
MIC EXTENSION CABLES
OPC-441
SPEAKER EXTENSION CABLE
OPC-1132/OPC-347
DC POWER CABLES
OPC-589
ADAPTER CABLE
CS-V8000
CLONING SOFTWARE
+ OPC-478
CLONING CABLE
OPC-474
CLONING CABLE
74
14
SPECIFICATIONS AND OPTIONS
13
14
