46
9
DTMF MEMORY ENCODER
9
■ Transmitting a DTMF code
D Automatic transmission (DTMF memory)
z Push [FUNC] then [
LOW
6(DTMF)] to turn the
DTMF memory encoder ON.
•“d” appears in place of the 100 MHz digit.
x Push [
SET
B(D-OFF)] to enter the DTMF mem-
ory programming condition.
c Push [Y] or [Z] to select the desired channel.
v Push [PTT] to transmit the selected memory.
• Exit the programming condition automatically.
• Each push of [PTT] transmits the DTMF code.
b Push [FUNC] then [
SET
B(D-OFF)] to cancel the
DTMF memory encoder.
• When the DTMF encoder is turned ON continuously,
each push of the PTT transmits the previously se-
lected DTMF code.
D Transmitting a DTMF memory directly
z Push [FUNC] then [
LOW
6(DTMF)] to turn the
DTMF memory encoder ON.
•“d” appears in place of the 100 MHz digit.
x
Push [DTMF-S] to turn the DTMF memory di-
rect selection ON.
• The function indicator (microphone) lights green.
c Push the desired DTMF channel number.
•“0” to “9” are available for channel numbers.
• The selected DTMF code is automatically transmit-
ted without pushing PTT.
D Transmitting a DTMF memory directly— continued
NOTE: When no DTMF code programmed
channel number is pushed, it transmits previ-
ously transmitted DTMF memory code.
v Push [DTMF-S] again to deactivate the DTMF
memory direct selection.
b Push [FUNC] then [
SET
B(D-OFF)] to cancel
the DTMF memory encoder.
D Manual transmission
z Deactivate the DTMF memory encoder by
pushing [FUNC] then [
SET
B(D-OFF)].
x
Push [DTMF-S] to turn the DTMF direct selec-
tion ON.
• The function indicator (microphone) lights green.
c Push one of “A” to “F” keys momentarily, then
push the desired DTMF keys, 0–9 and A to F.
• A: [
CLR
A(MW)] B: [
SET
B(D-OFF)],
C: [
ENT
C(T-OFF)] D: [
SQL
Y D(MUTE)],
E: [
MM
(TONE-1)] F: [
SQL
Z #(16KEY-L)]
• Automatically transmits without pushing PTT.
• The first code, one of “A” to “F,” is not transmitted.
DTMF code transmission starts from the 2nd code.
v Push [DTMF-S] again to deactivate the DTMF
direct selection.
DTMF-S
DTMF-S
DTMF-S
DTMF
