76
15
MODE ARRANGEMENT
15
SET
LOCK
S.MW
MW
SET
LOCK
S.MW
MW
SET MODE INITIAL SET MODE
Display dimmer (p. 59)
Display color (p. 59)
Repeater tone (p. 59)
Tone squelch tone (p. 59)
DTCS code and polarity (p. 59)
Offset frequency (p. 60)
Reverse mode (p. 60)
Tuning step (p. 60)*
4
Scan resume timer (p. 60)
Transmit permission (p. 60)
Skip setting*
1
(p. 61)
Wide/Nar. selection*
3
(p. 61)
Cooling fan setting (p. 61)
Weather alert*
2
(p. 61)
Turn power ON while pushing [SET(LOCK)].
Beep tone
on/off (p. 63)
Time-out
timer (p. 63)
Auto repeater*
2
(p. 63)
Auto power-
off (p. 64)
Repeater
lockout
(p. 64)
Squelch
delay (p. 64)
DTMF speed
(p. 64)
Display type
(p. 65)
Squelch
attenuator
(p. 65)
