27
5 MEMORY OPERATION
■
Transferring memory contents
This function transfers a memory channel’s contents to VFO
(or another memory/call channel). This is useful when search-
ing for signals around a memory channel frequency and for
recalling the offset frequency, subaudible tone frequency etc.
D Memory/call➪VFO
q Select the memory/call channel to be transferred.
➥ Push [M/CALL(PRIO)] to select memory mode, then ro-
tate the tuning dial to select the desired memory chan-
nel.
➥ Push [M/CALL(PRIO)] for 1 sec. to select the call chan-
nel.
w Push [MW(S.MW)] for 1 sec. to transfer the selected mem-
ory/call channel contents to the VFO.
• VFO mode is selected automatically.
z Select the memory/call channel to be
transferred.
➥ Push [MR/CALL] to select memory mode,
then select the desired memory channel
via [Y]/[Z] or keypad.
➥ Push [MR/CALL] for 1 sec. to select the
call channel.
x Push [FUNC], then [
CLR
A(MW)] for 1 sec. to
transfer the selected memory/call channel
contents to the VFO.
• VFO mode is selected automatically.
MR/CALL
MW
[Y]/[Z]
[EXAMPLE]: Transferring memory channel 30 contents to VFO.
Push to select memory mode.
Front panel operation:
HM-133V operation:
Push to select memory mode.
Rotate for selecting memory channel.
Select memory channel.
Push for 1 sec.
Push then push for 1 sec.
S.MW
MW
PRIO
M/CALL
