QUICK REFERENCE GUIDE
■ Installation
D Location
Select a location which can support the weight of the trans-
ceiver and does not interfere with driving in any way. We rec-
ommend the locations shown in the diagram below.
NEVER place the transceiver where normal operation of the
vehicle may be hindered or where it could cause bodily injury.
NEVER place the transceiver where air bag deployment may
be obstructed.
DO NOT place the transceiver where hot or cold air blows di-
rectly onto it.
AVOID placing the transceiver in direct sunlight.
D Using the mounting bracket
➀ Drill 4 holes where the mounting bracket is to be installed.
• Approx. 5.5–6 mm (
1
⁄4″) when using nuts; approx. 2–3 mm (
1
⁄8″)
when using self-tapping screws.
➁ Insert the supplied screws, nuts and washers through the
mounting bracket and tighten.
➂ Adjust the angle for the clearest view of the function dis-
play.
Nut
Spring washer
Flat washer
Spring
washer
When using
self-tapping
screws
Mounting
nut
Mounting
bracket
• Example— Installation location
