67
12 OTHER FUNCTIONS
■ Microphone keys
The supplied HM-133V’s (optional for some versions) [F-1]
and [F-2] keys memorize the transceiver conditions.
The [UP]/[DN] keys of the standard or an optional microphone
(other than the HM-133V) can be assigned functions like the
function keys on the transceiver’s front panel.
DD
[F-1]/[F-2] keys on HM-133V
The following conditions can be memorized into [F-1] and
[F-2] keys, independently.
• Operating frequency
• Repeater setting
(offset direction and frequency, tone
ON/OFF and frequency)
• Tone/DTCS squelch
(ON/OFF, frequency/code and polarity)
• Transmit output power selection
• Set mode settings
• Initial set mode settings
(except display type item)
➥ Programming the condition
Set the desired contents of each condition,
then push [F-1]/[F-2] for 1 sec.
• 3 beeps sound.
➥ Re-calling the condition
Push [F-1]/[F-2] momentarily.
DD
[UP]/[DN] keys on a microphones
(other than HM-133V)
The following functions are assigned to the [UP]/[DN] keys on
the other microphones (HM-118N/TAN, etc.) when first apply-
ing power.
[UP] : channel up; push and hold to start scan, push again
to stop scan.
[DN] : channel down; push and hold to start scan, push
again to stop scan.
➥ Assigning a function
q Turn the power OFF.
w While pushing the desired switch on the transceiver and
one of either [UP]/[DN] keys on the microphone, turn the
power ON.
• The function is programmed into the key.
➥ Clearing an assignment
q Turn the power OFF.
w While pushing the desired [UP] or [DN] key on the micro-
phone, turn the power ON.
AT
POWER ON
[F-1]/[F-2]
