Zyxel NXC5500 [153/469] Chapter 11 nat
![Zyxel NXC5500 [153/469] Chapter 11 nat](/views2/1169015/page153/bg99.png)
Chapter 11 NAT
NXC Series User’s Guide
153
Figure 78 Configuration > Network > NAT > Add/Edit
The following table describes the labels in this screen.
Table 76 Configuration > Network > NAT > Add/Edit
LABEL DESCRIPTION
Create new
Object
Use to configure any new settings objects that you need to use in this screen.
Enable Rule Use this option to turn the NAT rule on or off.
Rule Name Type in the name of the NAT rule. The name is used to refer to the NAT rule. You may use
1-31 alphanumeric characters, underscores(
_), or dashes (-), but the first character
cannot be a number. This value is case-sensitive.
