Chapter 14 Captive Portal
NXC Series User’s Guide
172
Source Address Select an address object from the list. If none are available, you can create a new one
using the Create New Object button.
The source address is an IP address for which the captive portal intercepts all network
traffic.
Destination
Address
Select an address object from the list. If none are available, you can create a new one
using the Create New Object button.
The destination address is an IP address for which the captive portal intercepts all network
traffic toward.
Schedule Select a schedule from the list. If none are available, you can create one in Configuration
> Object > Schedule.
Authentication Select whether authentication is required or not necessary for this rule.
Force User
Authentication
Select this option to redirect HTTP traffic to the login screen if the user has not logged in
yet.
OK Click OK to save your changes back to the NXC.
Cancel Click Cancel to exit this screen without saving.
Table 85 Configuration > Captive Portal > Auth. Policy Add/Edit
LABEL DESCRIPTION
