Chapter 7 Wireless
NXC Series User’s Guide
95
R1 Mode / Profile /
ZyMesh Profile
This field displays the operating mode (AP, MON, root, or repeater), AP radio profile
name and ZyMesh profile name for Radio 1. It displays n/a for the AP profile for a radio
not using an AP profile or - for the ZyMesh profile for a radio not using a ZyMesh profile.
R2 Mode / Profile /
ZyMesh Profile
This field displays the operating mode (AP, MON, root, or repeater), AP radio profile
name and ZyMesh profile name for Radio 2. It displays n/a for the AP radio profile for a
radio not using an AP radio profile or - for the ZyMesh profile for a radio not using a
ZyMesh profile.
Group This field displays the name of the AP group to which the AP belongs.
The group becomes editable immediately upon clicking.
Mgnt. VLAN ID(AC) This displays the Access Controller (the NXC) management VLAN ID setting for the AP.
Mgnt. VLAN ID(AP) This displays the runtime management VLAN ID setting on the AP. VLAN Conflict
displays if the AP’s management VLAN ID does not match the Mgnt. VLAN ID(AC).
This field displays n/a if the NXC cannot get VLAN information from the AP.
Description This field displays the AP’s description, which you can configure by selecting the AP’s
entry and clicking the Edit button.
Table 48 Configuration > Wireless > AP Management (continued)
LABEL DESCRIPTION
