Chapter 28 System
NXC Series User’s Guide
315
28.8.5 Examples of Secure Telnet Using SSH
This section shows two examples using a command interface and a graphical interface SSH client
program to remotely access the NXC. The configuration and connection steps are similar for most
SSH client programs. Refer to your SSH client program user’s guide.
28.8.5.1 Example 1: Microsoft Windows
This section describes how to access the NXC using the Secure Shell Client program.
1 Launch the SSH client and specify the connection information (IP address, port number) for the
NXC.
2 Configure the SSH client to accept connection using SSH version 1.
3 A window displays prompting you to store the host key in you computer. Click Yes to continue.
Server
Certificate
Select the certificate whose corresponding private key is to be used to identify the NXC for
SSH connections. You must have certificates already configured in the My Certificates
screen.
Service Control This specifies from which computers you can access which NXC zones.
Add Click this to create a new entry. Select an entry and click Add to create a new entry after
the selected entry.
Edit Double-click an entry or select it and click Edit to be able to modify the entry’s settings.
Remove To remove an entry, select it and click Remove. The NXC confirms you want to remove it
before doing so. Note that subsequent entries move up by one when you take this action.
Move To change an entry’s position in the numbered list, select the method and click Move to
display a field to type a number for where you want to put it and press [ENTER] to move
the rule to the number that you typed.
# This the index number of the service control rule.
Zone This is the zone on the NXC the user is allowed or denied to access.
Address This is the object name of the IP address(es) with which the computer is allowed or denied
to access.
Action This displays whether the computer with the IP address specified above can access the
NXC zone(s) configured in the Zone field (Accept) or not (Deny).
Apply Click Apply to save your changes back to the NXC.
Reset Click Reset to return the screen to its last-saved settings.
Table 162 Configuration > System > SSH (continued)
LABEL DESCRIPTION
