Chapter 30 File Manager
NXC Series User’s Guide
345
Line 3 in the following example exits sub command mode.
Lines 1 and 3 in the following example are comments and line 4 exits sub command mode.
Lines 1 and 2 are comments. Line 5 exits sub command mode.
Errors in Configuration Files or Shell Scripts
When you apply a configuration file or run a shell script, the NXC processes the file line-by-line. The
NXC checks the first line and applies the line if no errors are detected. Then it continues with the
next line. If the NXC finds an error, it stops applying the configuration file or shell script and
generates a log.
You can change the way a configuration file or shell script is applied. Include setenv stop-on-
error off in the configuration file or shell script. The NXC ignores any errors in the configuration
file or shell script and applies all of the valid commands. The NXC still generates a log for any
errors.
30.2 Configuration File
Click Maintenance > File Manager > Configuration File to open this screen. Use the
Configuration File screen to store, run, and name configuration files. You can also download
configuration files from the NXC to your computer and upload configuration files from your
computer to the NXC.
Once your NXC is configured and functioning properly, it is highly recommended that you back up
your configuration file before making further configuration changes. The backup configuration file
will be useful in case you need to return to your previous settings.
interface ge1
ip address dhcp
!
!
interface ge1
# this interface is a DHCP client
!
! this is from Joe
# on 2008/04/05
interface ge1
ip address dhcp
!
