Chapter 7 Wireless
NXC Series User’s Guide
98
7.3.2 Port Setting Edit
Use this screen to enable or disable a port on the managed AP and configure the port’s PVID.
To access this screen, select a port and click the Edit button in the Port Setting table of the
Configuration > Wireless > AP Management > Edit AP List screen.
Edit Select an SSID and click this button to reassign it. The selected SSID becomes editable
immediately upon clicking.
# This is the index number of the SSID profile. You can associate up to eight SSID profiles
with an AP radio.
SSID Profile Indicates which SSID profile is associated with this radio profile.
VLAN Settings
Override Group
VLAN Setting
Select this option to overwrite the AP VLAN setting with the setting you configure here.
Force Overwrite
VLAN Config
Select this to have the NXC change the AP’s management VLAN to match the
configuration in this screen.
Management VLAN
ID
Enter a VLAN ID for this AP.
As Native VLAN Select this option to treat this VLAN ID as a VLAN created on the NXC and not one
assigned to it from outside the network.
Port Settings
Override Group LAN
Setting
Select this option to overwrite the AP LAN port settings with the settings you configure
here.
Port Setting
# This is the port’s index number in this list.
Status This displays whether or not the port is activated.
Port This shows the name of the physical Ethernet port on the managed AP.
PVID This shows the port’s PVID.
A PVID (Port VLAN ID) is a tag that adds to incoming untagged frames received on a
port so that the frames are forwarded to the VLAN group that the tag defines.
VLAN Configuration
# This is the VLAN’s index number in this list.
Status This displays whether or not the VLAN is activated.
Name This shows the name of the VLAN.
VID This shows the VLAN ID number.
Member This field displays the Ethernet port(s) that is a member of this VLAN.
OK Click OK to save your changes back to the NXC.
Cancel Click Cancel to close the window with changes unsaved.
Table 49 Configuration > Wireless > AP Management > Edit AP List (continued)
LABEL DESCRIPTION
