Zyxel NXC5500 [25/469] Front panel leds
![Zyxel NXC5500 [25/469] Front panel leds](/views2/1169015/page25/bg19.png)
Chapter 2 Hardware Installation and Connection
NXC Series User’s Guide
25
USB 2.0 Ports
Connect a USB storage device to a USB port on the NXC to archive the NXC system logs or save the
NXC operating system core dump to it.
2.2.3 Front Panel LEDs
This section describes the front panel LEDs.
2.2.3.1 NXC2500
The following table describes the LEDs.
2.2.3.2 NXC5500
The following table describes the LEDs.
TD 3 Green 6
DTR 4 White/Brown 7
RTS 7 Brown 8
Table 6 RJ-45-to-DB-9 Console Cable Color Codes
DB-9 SIGNAL DB-9 PIN# WIRE COLOR RJ45 PIN#
Table 7 Front Panel LEDs: NXC2500
LED COLOR STATUS DESCRIPTION
PWR Off The NXC is turned off.
Green On The NXC is turned on.
Red On There is a hardware component failure. Shut down the device, wait for a few
minutes and then restart the device (see Section 1.6 on page 21). If the LED
turns red again, then please contact your vendor.
SYS Green Off The NXC is not ready or has failed.
On The NXC is ready and running.
Blinking The NXC is booting.
Red On The NXC had an error or has failed.
P1~P6 Green On This port has a successful link to a 10/100 Mbps Ethernet network
Blinking The NXC is sending or receiving packets to/from a 10/100 Mbps Ethernet
network on this port
Orange On This port has a successful link to a 1000 Mbps Ethernet network.
Blinking The NXC is sending or receiving packets to/from a 1000 Mbps Ethernet
network on this port
Off There is no connection on this port.
Table 8 Front Panel LEDs: NXC5500
LED COLOR STATUS DESCRIPTION
PWR Green Off The NXC is turned off.
On The NXC is turned on.
