Appendix C Importing Certificates
NXC Series User’s Guide
420
12 The next time you start Internet Explorer and go to a ZyXEL Web Configurator page, a sealed
padlock icon appears in the address bar. Click it to view the page’s Website Identification
information.
Installing a Stand-Alone Certificate File in Internet Explorer
Rather than browsing to a ZyXEL Web Configurator and installing a public key certificate when
prompted, you can install a stand-alone certificate file if one has been issued to you.
1 Double-click the public key certificate file.
2 In the security warning dialog box, click Open.
3 Refer to steps 4-12 in the Internet Explorer procedure beginning on page 416 to complete the
installation process.
