Zyxel NXC5500 [52/469] Memory usage
![Zyxel NXC5500 [52/469] Memory usage](/views2/1169015/page52/bg34.png)
Chapter 4 Dashboard
NXC Series User’s Guide
52
4.2.2 Memory Usage
Use this screen to look at a chart of the NXC’s recent memory (RAM) usage. To access this screen,
click Show Memory Usage in the dashboard.
Figure 20 Dashboard > Memory Usage
The following table describes the labels in this screen.
4.2.3 Session Usage
Use this screen to look at a chart of the NXC’s recent traffic session usage. To access this screen,
click Show Active Sessions in the dashboard.
Refresh Interval Enter how often you want this window to be automatically updated.
Refresh Now Click this to update the information in the window right away.
Table 19 Dashboard > CPU Usage (continued)
LABEL DESCRIPTION
Table 20 Dashboard > Memory Usage
LABEL DESCRIPTION
The y-axis represents the percentage of RAM usage.
The x-axis shows the time period over which the RAM usage occurred
Refresh Interval Enter how often you want this window to be automatically updated.
Refresh Now Click this to update the information in the window right away.
