Zyxel NXC5500 [73/469] Chapter 5 monitor
![Zyxel NXC5500 [73/469] Chapter 5 monitor](/views2/1169015/page73/bg49.png)
Chapter 5 Monitor
NXC Series User’s Guide
73
Figure 34 Monitor > Wireless > AP Information > AP List > AP Information
The following table describes the labels in this screen.
Table 36 Monitor > Wireless > AP Information > AP List > AP Information
LABEL DESCRIPTION
Configuration
Status
This displays whether or not any of the AP’s configuration is in conflict with the NXC’s
settings for the AP.
Non Support If any of the AP’s configuration conflicts with the NXC’s settings for the AP, this field
displays which configuration conflicts. It displays n/a if none of the AP’s configuration
conflicts with the NXC’s settings for the AP.
Port Status
Port This shows the name of the physical Ethernet port on the NXC.
