![Zyxel NXC5500 [51/469] Cpu usage](/views2/1169015/page51/bg33.png)
Chapter 4 Dashboard
NXC Series User’s Guide
51
4.2.1 CPU Usage
Use this screen to look at a chart of the NXC’s recent CPU usage. To access this screen, click Show
CPU Usage in the dashboard.
Figure 19 Dashboard > CPU Usage
The following table describes the labels in this screen.
Un-Management
AP
This displays the number of non-managed APs.
All Station This section displays a summary of connected stations. Click the link to go to the
Station Info > Station List screen.
Station This displays the number of stations currently connected to the network.
All Sensed Device This sections displays a summary of all wireless devices detected by the network. Click
the link to go to the Rogue AP > Detected Device screen.
Un-Classified AP This displays the number of detected unclassified APs.
Rogue AP This displays the number of detected rogue APs.
Friendly AP This displays the number of detected friendly APs.
ZyMesh AP
Information
This shows a summary of managed APs that act as a root AP or a repeater to form a
ZyMesh/WDS.
All ZyMesh AP This section displays a summary for all ZyMesh APs. Click the link to go to the Monitor
> Wireless > All ZyMesh AP > ZyMesh Link Info screen.
Online ZyMesh
AP
This displays the number of currently connected ZyMesh APs.
Offline ZyMesh
AP
This displays the number of currently offline ZyMesh APs.
Table 18 Dashboard (continued)
LABEL DESCRIPTION
Table 19 Dashboard > CPU Usage
LABEL DESCRIPTION
The y-axis represents the percentage of CPU usage.
The x-axis shows the time period over which the CPU usage occurred
