ZyWALL/USG Series Handbook
35
CHAPTER 2
Set Up WiFi
2.1 How to Set Up a WiFi Network with ZyXEL APs
This is an example of using ZyWALL/USG to manage the Access Points (APs) and allow wireless
access to the network.
Figure 34 ZyWALL/USG as AP Controller Example
Note: All network IP addresses and subnet masks are used as examples in this article.
Please replace them with your actual network IP addresses and subnet masks. This
example was tested using USG310 (Firmware Version: ZLD 4.13).
2.1.1 Set Up the AP Management on the ZyWALL/USG
1 In the ZyWALL/USG, go to CONFIGURATION > Wireless > Controller > Configuration, set
Registration Type to Manual. This is recommended as the registration mechanism cannot
automatically differentiate between friendly and rogue APs.
Figure 35 CONFIGURATION > Wireless > Controller > Configuration
2 Connect the ZyXEL AP unit to the lan interface.
