Zyxel VMG1312-B10B [108/394] Chapter 7 wireless
![Zyxel VMG1312-B10B [108/394] Chapter 7 wireless](/views2/1169620/page108/bg6c.png)
Chapter 7 Wireless
VMG1312-B10B / VMG1312-B30B Series User’s Guide
108
Password 1~4 The password (WEP key) is used to encrypt data. Both the Device and the wireless stations
must use the same password (WEP key) for data transmission.
If you chose 64-bit WEP, then enter any 5 ASCII characters or 10 hexadecimal characters
("0-9", "A-F").
If you chose 128-bit WEP, then enter 13 ASCII characters or 26 hexadecimal characters
("0-9", "A-F").
You must configure at least one password, only one password can be activated at any one
time.
more.../less Click more... to show more fields in this section. Click less to hide them.
WEP Encryption Select 64-bits or 128-bits.
This dictates the length of the security key that the network is going to use.
IP Address Enter the IP address of an external RADIUS server in dotted decimal notation.
Port Number The default port of a RADIUS server for authentication is 1812. You need not change this
value unless your network administrator instructs you to do so.
Shared Secret Specify a password (up to 32 alphanumeric characters) as the key to be shared between the
external RADIUS server and the Device. This key is not sent over the network. This key
must be the same on the external RADIUS server and the Device.
Table 19 Wireless > General: Basic (802.1X) (continued)
LABEL DESCRIPTION
