Zyxel VMG1312-B10B [92/394] The 8021x screen
![Zyxel VMG1312-B10B [92/394] The 8021x screen](/views2/1169620/page92/bg5c.png)
Chapter 6 Broadband
VMG1312-B10B / VMG1312-B30B Series User’s Guide
92
6.5 The 8021x Screen
You can view and configure the 802.1X authentication settings in the 8021x screen. Click Network
Setting > Broadband > 8021x to display the following screen.
Figure 26 Network Setting > Broadband > 8021x
The following table describes the labels in this screen.
PhyR DS Enable or disable PhyR DS (downstream) for downstream transmission from the WAN.
PhyR DS should be enabled if data being transmitted downstream is sensitive to noise.
However, enabling PhyR DS can decrease the DS line rate. Enabling or disabling PhyR will
require the CPE to retrain. For PhyR to function, the DSLAM must also support PhyR and
have it enabled.
Apply Click Apply to save your changes back to the Device.
Cancel Click Cancel to return to the previous configuration.
Table 12 Network Setting > Network Setting > Broadband (continued)
LABEL DESCRIPTION
Table 13 Network Setting > Network Setting > 8021x
LABEL DESCRIPTION
# This is the index number of the entry.
Status This field displays whether the authentication is active or not. A yellow bulb signifies that
this authentication is active. A gray bulb signifies that this authentication is not active.
Interface This is the interface that uses the authentication. This displays N/A when there is no
interface assigned.
EAP Identity This shows the EAP identity of the authentication. This displays N/A when there is no EAP
identity assigned.
EAP method This shows the EAP method used in the authentication. This displays N/A when there is no
EAP method assigned.
Bidirectional
Authentication
This shows whether bidirectional authentication is allowed.
Certificate This shows the certificate used for this authentication. This displays N/A when there is no
certificate assigned.
Trusted CA This shows the Trusted CA used for this authentication. This displays N/A when there is no
Trusted CA assigned.
Apply Click Apply to save your changes back to the Device.
Cancel Click Cancel to return to the previous configuration.
