Chapter 7 Wireless

VMG1312-B10B / VMG1312-B30B Series User’s Guide

116

Note: The Device applies the security settings of the SSID1 profile (see Section 7.2 on

page 102). If you want to use the WPS feature, make sure you have set the

security mode of SSID1 to WPA2-PSK or No Security.

Click Network Setting > Wireless > WPS. The following screen displays. Select Enable and click

Apply to activate the WPS function. Then you can configure the WPS settings in this screen.

Figure 39 Network Setting > Wireless > WPS

The following table describes the labels in this screen.

Table 25 Network Setting > Wireless > WPS

LABEL DESCRIPTION

WPS Select Enable to activate WPS on the Device.

Method 1 Use this section to set up a WPS wireless network using Push Button Configuration (PBC).

Connect Click this button to add another WPS-enabled wireless device (within wireless range of the

Device) to your wireless network. This button may either be a physical button on the

outside of device, or a menu button similar to the Connect button on this screen.

Note: You must press the other wireless device’s WPS button within two minutes of pressing

this button.

Method 2 Use this section to set up a WPS wireless network by entering the PIN of the client into the

Device.

You can find the PIN either on the outside of the device, or by checking the device’s

settings.

Note: You must also activate WPS on that device within two minutes to have it present its PIN

to the Device.

Method 3 Use this section to set up a WPS wireless network by entering the PIN of the Device into the

client.
