VMG1312-B10B / VMG1312-B30B Series User’s Guide 273
CHAPTER 28
User Account
28.1 Overview
In the Users Account screen, you can change the password of the user account that you used to
log in the Device.
28.2 The User Account Screen
Click Maintenance > User Account to open the following screen.
Figure 138 Maintenance > User Account
The following table describes the labels in this screen.
Table 107 Maintenance > User Account
LABEL DESCRIPTION
User Name This field displays the name of the account that you used to log in the system.
Old Password Type the default password or the existing password you use to access the system in this
field.
New Password Type your new system password (up to 256 characters). Note that as you type a password,
the screen displays a (*) for each character you type. After you change the password, use
the new password to access the Device.
Retype to
confirm
Type the new password again for confirmation.
Apply Click Apply to save your changes.
Cancel Click Cancel to restore your previously saved settings.
