Chapter 4 Tutorials
VMG1312-B10B / VMG1312-B30B Series User’s Guide
40
The following figure shows you an example of how to set up a wireless network and its security by
pressing a button on both Device and wireless client.
Example WPS Process: PBC Method
Wireless Client
Device
SECURITY INFO
COMMUNICATION
WITHIN 2 MINUTES
Press and hold for
5 seconds
WLAN/
WPS
