Chapter 6 Broadband

VMG1312-B10B / VMG1312-B30B Series User’s Guide

6.5.1 Edit 802.1X Settings

Use this screen to edit 802.1X authentication settings. Click the Edit icon next to the rule you want

to edit. The screen shown next appears.

Figure 27 802.1x: Add/Edit

The following table describes the labels in this screen.

6.6 The Ethernet WAN Screen

If you are using an ethernet WAN connection, you can configure a LAN port as an ethernet WAN

port. Click Network Setting > Broadband > Ethernet WAN to open this screen.

Note: LAN port 4 can operate as an Ethernet WAN port.

Table 14 802.1x: Add/Edit

LABEL DESCRIPTION

Active This field allows you to activate/deactivate the authentication.

Select this to enable the authentication. Clear this to disable this authentication without

having to delete the entry.

EAP Identity Enter the EAP identity of the authentication.

EAP method This is the EAP method used for this authentication.

Enable

Bidirectional

Authentication

Select this to allow bidirectional authentication.

Certificate Select the certificate you want to assign to the authentication. You need to import the

certificate in the Security > Certificates > Local Certificates screen.

Trusted CA Select the Trusted CA you want to assign to the authentication. You need to import the

certificate in the Security > Certificates > Trusted CA screen.

Apply Click Apply to save your changes.

Cancel Click Cancel to exit this screen without saving.
