Chapter 7 Wireless
VMG1312-B10B / VMG1312-B30B Series User’s Guide
114
7.4 MAC Authentication
This screen allows you to configure the ZyXEL Device to give exclusive access to specific devices
(Allow) or exclude specific devices from accessing the ZyXEL Device (Deny). Every Ethernet
device has a unique MAC (Media Access Control) address. The MAC address is assigned at the
factory and consists of six pairs of hexadecimal characters, for example, 00:A0:C5:00:00:02. You
need to know the MAC addresses of the devices to configure this screen.
Wireless
Network Name
(SSID)
The SSID (Service Set IDentity) identifies the service set with which a wireless device is
associated. Wireless devices associating to the access point (AP) must have the same SSID.
Enter a descriptive name (up to 32 English keyboard characters) for the wireless LAN.
Max clients Specify the maximum number of clients that can connect to this network at the same time.
Hide SSID Select this check box to hide the SSID in the outgoing beacon frame so a station cannot
obtain the SSID through scanning using a site survey tool.
Enhanced
Multicast
Forwarding
Select this check box to allow the Device to convert wireless multicast traffic into wireless
unicast traffic.
Guest WLAN Select this to create Guest WLANs for home and external clients. Select the WLAN type in
the Access Scenario field.
Access
Scenario
If you select Home Guest, clients can connect to each other directly.
If you select External Guest, clients are blocked from connecting to each other directly.
Maximum
Upstream
Bandwidth
Specify the maximum rate for upstream wireless traffic to the WAN from this WLAN in
kilobits per second (Kbps).
Maximum
Downstream
Bandwidth
Specify the maximum rate for downstream wireless traffic to this WLAN from the WAN in
kilobits per second (Kbps).
Security Level
Security Mode Select Basic (WEP, 802.1X) or More Secure (WPA(2)-PSK, WPA(2)) to add security
on this wireless network. The wireless clients which want to associate to this network must
have same wireless security settings as the Device. After you select to use a security,
additional options appears in this screen.
Or you can select No Security to allow any client to associate this network without any data
encryption or authentication.
See Section 7.2.1 on page 105 for more details about this field.
Apply Click Apply to save your changes.
Cancel Click Cancel to exit this screen without saving.
Table 23 More AP: Edit (continued)
LABEL DESCRIPTION
