Chapter 20 VPN
VMG1312-B10B / VMG1312-B30B Series User’s Guide
242
This screen contains the following fields:
20.2.2 IPSec VPN: Add
Use these settings to add or edit VPN policies. Click Security > VPN > Add new connection to
open this screen as shown next.
Table 92 IPSec VPN
LABEL DESCRIPTION
Add new
connection
Click this button to add an item to the list.
Enable This displays if the VPN policy is enabled.
Connection Name The name of the VPN connection.
Remote Gateway This is the IP address of the remote IPSec router in the IKE SA.
Local Addresses This displays the IP address(es) on the LAN behind your Device.
Remote
Addresses
This displays the IP address(es) on the LAN behind the remote IPSec’s router.
Delete Click the Delete icon to delete an existing rule.
