Chapter 7 Wireless
VMG1312-B10B / VMG1312-B30B Series User’s Guide
113
7.3.1 Edit More AP
Use this screen to edit an SSID profile. Click the Edit icon next to an SSID in the More AP screen.
The following screen displays.
Figure 37 More AP: Edit
The following table describes the fields in this screen.
Table 23 More AP: Edit
LABEL DESCRIPTION
Wireless Network Setup
Wireless You can Enable or Disable the wireless LAN in this field.
Passphrase
Type
Passphrase type cannot be changed. The default is None.
Wireless Network Settings
