Chapter 10 Quality of Service (QoS)

VMG1312-B10B / VMG1312-B30B Series User’s Guide

177

10.6 The QoS Policer Setup Screen

Use this screen to configure QoS policers that allow you to limit the transmission rate of incoming

traffic. Click Network Setting > QoS > Policer Setup. The screen appears as shown.

Figure 72 Network Setting > QoS > Policer Setup

The following table describes the labels in this screen.

To Queue Index Select a queue that applies to this class.

You should have configured a queue in the Queue Setup screen already.

Apply Click Apply to save your changes.

Cancel Click Cancel to exit this screen without saving.

Table 48 Class Setup: Add/Edit (continued)

LABEL DESCRIPTION

Table 49 Network Setting > QoS > Policer Setup

LABEL DESCRIPTION

Add new Policer Click this to create a new entry.

# This is the index number of the entry.

Status This field displays whether the policer is active or not. A yellow bulb signifies that this

policer is active. A gray bulb signifies that this policer is not active.

Name This field displays the descriptive name of this policer.

Regulated

Classes

This field displays the name of a QoS classifier

Meter Type This field displays the type of QoS metering algorithm used in this policer.

Rule These are the rates and burst sizes against which the policer checks the traffic of the

member QoS classes.

Action This shows the how the policer has the Device treat different types of traffic belonging to

the policer’s member QoS classes.

Modify/Delete Click the Edit icon to edit the policer.

Click the Delete icon to delete an existing policer. Note that subsequent rules move up by

one when you take this action.
