VMG1312-B10B / VMG1312-B30B Series User’s Guide 265
CHAPTER 25
IGMP Status
25.1 Overview
Use the IGMP Status screens to look at IGMP group status and traffic statistics.
25.2 The IGMP Group Status Screen
Use this screen to look at the current list of multicast groups the Device has joined and which ports
have joined it. To open this screen, click System Monitor > IGMP Group Status.
Figure 135 System Monitor > IGMP Group Status
The following table describes the labels in this screen.
Table 104 System Monitor > IGMP Group Status
LABEL DESCRIPTION
Interface This field displays the name of an interface on the Device that belongs to an IGMP multicast
group.
Multicast Group This field displays the name of the IGMP multicast group to which the interface belongs.
Filter Mode INCLUDE means that only the IP addresses in the Source List get to receive the multicast
group’s traffic.
EXCLUDE means that the IP addresses in the Source List are not allowed to receive the
multicast group’s traffic but other IP addresses can.
Source List This is the list of IP addresses that are allowed or not allowed to receive the multicast
group’s traffic depending on the filter mode.
