Chapter 37 Diagnostic
VMG1312-B10B / VMG1312-B30B Series User’s Guide
301
Note: This screen is available only when you configure an ATM layer-2 interface.
Figure 160 Maintenance > Diagnostic > OAM Ping
The following table describes the fields in this screen.
Table 119 Maintenance > Diagnostic > OAM Ping
LABEL DESCRIPTION
Select a PVC on which you want to perform the loopback test.
F4 segment Press this to perform an OAM F4 segment loopback test.
F4 end-end Press this to perform an OAM F4 end-to-end loopback test.
F5 segment Press this to perform an OAM F5 segment loopback test.
F5 end-end Press this to perform an OAM F5 end-to-end loopback test.
