Chapter 2 The Web Configurator
VMG1312-B10B / VMG1312-B30B Series User’s Guide
29
QoS General Use this screen to enable QoS and traffic prioritizing. You can also
configure the QoS rules and actions.
Queue Setup Use this screen to configure QoS queues.
Class Setup Use this screen to define a classifier.
Policer Setup Use these screens to configure QoS policers.
Monitor Use this screen to view QoS packets statistics.
NAT Port Forwarding Use this screen to make your local servers visible to the outside
world.
Applications Use this screen to configure servers behind the Device.
Port Triggering Use this screen to change your Device’s port triggering settings.
DMZ Use this screen to configure a default server which receives packets
from ports that are not specified in the Port Forwarding screen.
ALG Use this screen to enable or disable SIP ALG.
Address Mapping Use this screen to change your Device’s address mapping settings.
DNS DNS Entry Use this screen to view and configure DNS routes.
Dynamic DNS Use this screen to allow a static hostname alias for a dynamic IP
address.
Interface
Group
Use this screen to map a port to a PVC or bridge group.
USB Device File Sharing Use this screen to enable file sharing via the Device.
Media Server Use this screen to use the Device as a media server.
Printer Server Use this screen to enable the print server on the Device and get the
model name of the associated printer.
Security Settings
Firewall General Use this screen to configure the security level of your firewall.
Service Use this screen to add Internet services and configure firewall rules.
Access Control Use this screen to enable specific traffic directions for network
services.
DoS Use this screen to activate protection against Denial of Service (DoS)
attacks.
MAC Filter Use this screen to block or allow traffic from devices of certain MAC
addresses to the Device.
Parental
Control
Use this screen to block web sites with the specific URL.
Scheduler Rule Use this screen to configure the days and times when a configured
restriction (such as parental control) is enforced.
Certificates Local Certificates Use this screen to view a summary list of certificates and manage
certificates and certification requests.
Trusted CA
Use this screen to view and manage the list of the trusted CAs.
IPSec VPN Use this screen to add or edit VPN policies.
System Monitor
Log System Log Use this screen to view the status of events that occurred to the
Device. You can export or e-mail the logs.
Security Log Use this screen to view the login record of the Device. You can export
or e-mail the logs.
Table 3 Navigation Panel Summary (continued)
LINK TAB FUNCTION
