Chapter 20 VPN
VMG1312-B10B / VMG1312-B30B Series User’s Guide
243
Figure 123 IPSec VPN: Add
This screen contains the following fields:
Table 93 IPSec VPN: Add
LABEL DESCRIPTION
IPSec Setup
IPSec
Connection
Name
Enter the name of the VPN connection.
