Chapter 14 USB Service
VMG1312-B10B / VMG1312-B30B Series User’s Guide
216
To access this screen, click Network Setting > USB Service > Printer Server.
Figure 101 Network Setting > USB Service > Printer Server
The following table describes the labels in this menu.
Table 74 Network Setting > USB Service > Print Server
LABEL DESCRIPTION
Printer Server Select Enable to have the Device share a USB printer.
Apply Click Apply to save your changes.
Cancel Click Cancel to restore your previously saved settings.
