4 Configure VLAN-to-Instance
mapping table of the MST
region
On Spanning Tree→MSTP Instance→Instance
Config page, configure VLAN-to-Instance mapping
table. Map VLAN 101, 103 and 105 to Instance 1;
map VLAN 102, 104 and 106 to Instance 2.
Configure Switch B:
Step
Operation
Description
1 Configure ports On VLAN→802.1Q VLAN→VLAN Config page,
configure the link type of the related ports as
Tagged, and add the ports to VLAN101-VLAN106.
The detailed instructions can be found in the section
802.1Q VLAN.
2 Enable STP function On Spanning Tree→STP Config→STP Config page,
enable STP function and select MSTP version.
On Spanning Tree→STP Config→Port Config page,
enable MSTP function for the port.
3 Configure the region name and
the revision of MST region
On Spanning Tree→MSTP Instance→Region Config
page, configure the region as TP-Link and keep the
default revision setting.
4 Configure VLAN-to-Instance
mapping table of the MST
region
On Spanning Tree→MSTP Instance→Instance
Config page, configure VLAN-to-Instance mapping
table. Map VLAN 101, 103 and 105 to Instance 1;
map VLAN 102, 104 and 106 to Instance 2.
5 Configure switch B as the root
bridge of Instance 1
On Spanning Tree→MSTP Instance→Instance
Config page, configure the priority of Instance 1 to
be 0.
6
Configure switch B as the
designated bridge of Instance
2
On Spanning Tree→MSTP Instance→Instance
Config page, configure the priority of Instance 2 to
be 4096.
Configure Switch C:
Step
Operation
Description
1 Configure ports On VLAN→802.1Q VLAN→VLAN Config page,
configure the link type of the related ports as
Tagged, and add the ports to VLAN101-VLAN106.
The detailed instructions can b
e found in the
section 802.1Q VLAN.
2 Enable STP function On Spanning Tree→STP Config→STP Config page,
enable STP function and select MSTP version.
On Spanning Tree→STP Config→Port Config
page, enable MSTP function for the port.
3
Configure the region name and
On Spanning Tree→MSTP Instance→Region
119
