the revision of MST region
Config page, configure the region as TP-Link and
keep the default revision setting.
4 Configure VLAN-to-Instance
mapping table of the MST
region
On Spanning TreeMSTP InstanceInstance
Config page, configure VLAN-to-Instance mapping
table. Map VLAN101, 103
and 105 to Instance 1;
map VLAN102, 104 and 106 to Instance 2.
5
Configure switch C as the root
bridge of Instance 1
On Spanning TreeMSTP InstanceInstance
Config page, configure the priority of Instance 1 to
be 4096.
6
Configure switch C as the root
bridge of Instance 2
On Spanning TreeMSTP InstanceInstance
Config page, configure the priority of Instance 2 to
be 0.
Configure Switch D:
Step
Operation
Description
1 Configure ports On VLAN802.1Q VLANVLAN Config page,
configure the link type of the related ports as
Tagged, and add the ports to VLAN101-VLAN106.
The detailed instructions can be found in the
section 802.1Q VLAN.
2 Enable STP function On Spanning TreeSTP ConfigSTP Config page,
enable STP function and select MSTP version.
On Spanning TreeSTP ConfigPort Config
page, enable MSTP function for the port.
3 Configure the region name and
the revision of MST region
On Spanning TreeMSTP InstanceRegion
Config page, configure the region as TP-Link and
keep the default revision setting.
4 Configure VLAN-to-Instance
mapping table of the MST
region
On Spanning TreeMSTP InstanceInstance
Config page, configure VLAN-to-Instance mapping
table. Map VLAN101, 103
and 105 to Instance 1;
map VLAN102, 104 and 106 to Instance 2.
The configuration procedure for switch E and F is the same with that for switch D.
The topology diagram of the two instances after the topology is stable
For Instance 1 (VLAN101, 103 and 105), the red paths in the following figure are connected
links; the gray paths are the blocked links.
