Shut Mode: Once detecting a unidirectional link, the port can be shut down
in one of the following two modes:
• Auto: In this mode, DLDP generates logs and traps and
shuts down the corresponding port on detecting
unidirectional links, and the DLDP link state transits to
Disable.
• Manual: In this mode, DLDP only generates logs and traps if
it detects unidirectional links, and the operation to shut
down the unidirectional link ports is accomplished by the
administrator.
Web Refresh State:
Enable/Disable the web automatic refresh function.
Web Refresh
Interval:
Configure the interval to refresh the web page, ranging from 1
to 100 seconds, and the default value is 5 seconds.
Port Config
Select:
Select the desired port for configuration. It is multi-optional.
Port:
Port list of the switch.
DLDP State:
Enable/Disable DLDP on the selected port.
Protocol State:
Displays the DLDP protocol state.
Link State:
Displays the state of the links.
Neighbor State:
Displays the state of the selected port’s neighbor.
Configuration Procedure:
Step
Operation
Description
1
Enable DLDP globally. Required. On the Ethernet OAM→DLDP→DLDP Config
page, configure DLDP State as Enable under the Global
Config tab.
2
Enable DLDP on the
specified port.
Required. On the Ethernet OAM→DLDP→DLDP Config
page, configure DLDP State as Enable on specified port in
the Port Config table.
3
Configure Shut Mode. Optional. On the Ethernet OAM→DLDP→DLDP Config
page, configure the Shut Mode as Auto or Manual under the
Global Config tab.
4
Reset DLDP state. Optional. On the Ethernet OAM→DLDP→DLDP Config
page, select the specified ports or select all the ports in the
Port Config table and click the Reset button to restore their
state.
139
