When the PoE LED is on, the port LED is indicating the power supply status. By default the
Speed LED is on. Pressing the mode switch button, the Speed LED will turn off and the PoE LED
will light up. Then the PoE LED will turn off after being on for 60 seconds and the Speed LED will
light up again.
When the Speed LED is on, the port LED is indicating the data transmission status.
LEDs
Name
Status
Indication
PWR
On
The switch is powered on.
Off
The switch is powered off or power supply is
abnormal.
Flashing
Power supply is abnormal.
SYS
Flashing
The switch works properly.
On/Off
The switch works improperly.
FAN
Green
All the fans work properly.
Yellow
Not all the fans work properly.
Off
The switch works improperly.
Speed or
PoE (Port
1-24）
Green
On
A 1000Mbps device is connected to the
corresponding port but no activity.
Flashing
A 1000Mbps device is connected to the
corresponding port and data is being transmitted or
received.
Yellow
On
A 10/100Mbps device is connected to the
corresponding port but no activity.
Flashing
A 10/100Mbps device is connected to the
corresponding port and data is being transmitted or
received.
Off
No device is connected to the corresponding port.
1000Base-X
(Port 25-28)
On
There is a device linked to the corresponding SFP
port but no activity.
Flashing
The corresponding SFP port is transmitting or
receiving data.
Off
There is no device linked to the corresponding SFP
port.
When the PoE LED is on, the port LED is indicating the power supply status.
LEDs
Name
Status
Indication
PWR
On
The switch is powered on.
11
