Si34-803 Special Control
Function 145
3.3 Oil Return Operation
In order to prevent the compressor from running out of oil, the oil return operation is conducted to recover oil flown out
from the compressor to the system side.
3.3.1 Oil Return Operation in Cooling Operation
[Start conditions]
Referring to the set conditions for the following items, start the oil return operation in cooling.
• Cumulative oil feed rate
• Timer setting (Make this setting so as to start the oil return operation when the initial cumulative operating time
reaches two hours after power supply is turned ON and then every eight hours.)
Furthermore, the cumulative oil feed rate is computed from Tc, Te, and compressor loads.
* In the case of multi-outdoor-unit system,
Master unit: Performs the operations listed in the table above.
Slave units: Operating units perform the operations listed in the table above.
Non-operating units perform the operations listed in the table above from the oil return operation.
(Non-operating unit stops during “oil return preparation operation”.)
* Actuators are based on RXYQ14~18P(A).
Outdoor unit actuator
Oil return preparation
operation
Oil return operation Post-oil-return operation
Compressor
Take the current step as the
upper limit.
5 HP: 52 Hz
(→ Low pressure constant
control)
Other model:
52 Hz + ON + ON
(→ Low pressure
constant control)
↓
Maintain number of
compressors in oil
return preparation
operation ON
Same as the
“
oil return
operation
”
mode.
Outdoor unit fan Fan control (Normal cooling) Fan control (Normal cooling) Fan control (Normal cooling)
Four way valve OFF OFF OFF
Main motorized valve (EV1) 480 pls 480 pls 480 pls
Subcooling motorized valve (EV2) SH control 0 pls 0 pls
Hot gas bypass valve (SVP) OFF OFF OFF
Accumulator oil return valve (SVO) ON ON ON
Ending conditions 20 sec.
• 3 min.
• Ts - Te<5°C
• 3 min.
• Pe<0.6MPa
• HTdi>110°C
or
or
Indoor unit actuator Cooling oil return operation
Fan
Thermostat ON unit Remote controller setting
Stopping unit OFF
Thermostat OFF unit Remote controller setting
Electronic expansion valve
Thermostat ON unit Normal opening
Stopping unit 224 pls
Thermostat OFF unit Normal opening with forced thermostat ON
