Si34-803 Troubleshooting by Indication on the Remote Controller
Troubleshooting 333
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
NO
Replace the outdoor unit PC
Board (A1P).
YES
C/H SELECT is set to "IND".
Cool / heat selection is
unified.
C/H SELECT
is set to
"MASTER."
NO
C/H SELECT
is set to
"SLAVE."
YES
NO
Check
and see if the following items
are normal.
NO
Does a
malfunction occur when
the cool / heat selector is
set to "IND?"
YES
Set C/H SELECT to "IND."
Fix the outdoor units multi
connection transmission
wiring and reset power.
NO
Is there any
broken wire or erroneous
wire connection in the
communication wiring of
multi outdoor unit
system?
YES
The cool / heat unified
address for outdoor units in
outdoor - outdoor unit
transmission is duplicated.
Set the address correctly.
YES
NO
NO
YES
YES
Replace external control
adaptor for outdoor unit
Replace the outdoor unit PC
board (A1P).
External control adaptor for outdoor unit
•Is this PC board energized?
•Does the cool/heat unified address match?
Outdoor unit (unified master unit)
•Is this energized?
•Does the cool/heat unified address match?
Fix the problem.
