Option List Si34-803
420 Appendix
System Configuration
Note:
1. Installation box for * adaptor must be obtained locally.
2. For residential use only. Cannot be used with other centralized control equipment.
Building Management System
Note:
*1. BACnet
®
is a registered trademark of American Society of Heating, Refrigerating and Air-
Conditioning Engineers (ASHRAE).
*2. LONWORKS
®
is a registered trade mark of Echelon Corporation.
*3. Installation box for * adaptor must be procured on site.
No. Item Model No. Function
1 Residential central remote controller
Note *2
DCS303A51
Up to 16 groups of indoor units (128 units) can be easily controlled using the large LCD
panel. ON/OFF, temperature settings and scheduling can be controlled individually for
indoor units.
2 Central remote controller DCS302CA61
Up to 64 groups of indoor units(128 units) can be connected, and ON/OFF, temperature
setting and monitoring can be accomplished individually or simultaneously. Connectable up
to 2 controllers in one system.
2-1
Electrical box with earth terminal (3 blocks)
KJB311AA
3 Unified ON/OFF controller DCS301BA61
Up to 16 groups of indoor units(128 units) can be turned, ON/OFF individually or
simultaneously, and operation and malfunction can be displayed. Can be used in
combination with up to 8 controllers.
3-1
Electrical box with earth terminal (2 blocks)
KJB212AA
3-2
Noise filter (for electromagnetic
interface use only)
KEK26-1A
4 Schedule timer DST301BA61
Programmed time weekly schedule can be controlled by unified control for up to 64 groups
of indoor units (128 units). Can turn units ON/OFF twice per day.
5
Interface adaptor for
SkyAir-series
For SkyAir,
FD(Y)M-FA,
FDY-KA
FDYB-KA,
FVY(P)J-A
*DTA102A52
Adaptors required to connect products other than those of the VRV System to the high-
speed DIII-NET communication system adopted for the VRV System.
* To use any of the above optional controllers, an appropriate adaptor must be installed on
the product unit to be controlled.
6
Central control
adaptor kit
For UAT(Y)-
K(A),FD-K
*DTA107A55
7 Wiring adaptor for other air-conditioner *DTA103A51
Up to 1024 units can be centrally controlled in 64 different groups.
Wiring restrictions (max. length : 1,000m, total wiring length : 2,000m, max. number of
branches : 16) apply to each adaptor.
8 DIII-NET Expander Adaptor DTA109A51
8-1 Mounting plate KRP4A92
Fixing plate for DTA109A51
No. Part name Model No. Function
1
intelligent Touch
Controller
Basic Hardware
intelligent Touch
Controller
DCS601C51
Air-Conditioning management system that can be controlled by
a compact all-in-one unit.
1-1
Option
Hardware DIII-NET plus adaptor DCS601A52
Additional 64 groups (10 outdoor units) is possible.
1-2
Software
P.P.D. DCS002C51
P. P. D.: Power Proportional Distribution function
1-3 Web DCS004A51
Monitors and controls the air conditioning system using the
Internet and a Web browser application on a PC.
1-4 Electrical box with earth terminal (4 blocks) KJB411A
Wall embedded switch box.
2
intelligent
Manager III
Basic Hardware
Number of
units to be
connected
128 units DAM602B52
Air conditioner management system that can be controlled by
personal computers.
256 units DAM602B51
512 units DAM602B51x2
768 units DAM602B51x3
1024 units DAM602B51x4
2-1
Option Software
P.P.D. DAM002A51
Power Proportional Distribution function
2-2 Web DAM004A51
Monitors and controls the air conditioning system using the
Internet and a Web browser application on a PC.
2-3 Eco DAM003A51
ECO (Energy saving functions.)
2-4 Optional DIII Ai unit DAM101A51
External temperature sensor for intelligent Manager III.
2-5 Di unit DEC101A51
8 pairs based on a pair of On/Off input and abnormality input.
2-6 Dio unit DEC102A51
4 pairs based on a pair of On/Off input and abnormality input.
3
Communication line
*1 Interface for use in BACnet
®
DMS502B51
Interface unit to allow communications between VRV and BMS.
Operation and monitoring of air-conditioning systems through
BACnet® communication.
3-1 Optional DIII board DAM411B51
Expansion kit, installed on DMS502B51, to provide 2 more DIII-
NET communication ports. Not usable independently.
3-2 Optional Di board DAM412B51
Expansion kit, installed on DMS502B51, to provide 16 more
wattmeter pulse input points. Not usable independently.
4 *2 Interface for use in LONWORKS
®
DMS504B51
Interface unit to allow communications between VRV and BMS.
Operation and monitoring of air-conditioning systems through
LONWORKS
®
communication.
5
Contact/analog
signal
Parallel interface
Basic unit
DPF201A51
Enables ON/OFF command, operation and display of
malfunction; can be used in combination with up to 4 units.
6
Temperature
measurement units
DPF201A52
Enables temperature measurement output for 4 groups; 0-
5VDC.
7
Temperature
setting units
DPF201A53
Enables temperature setting input for 16 groups; 0-5VDC.
8
Unification adaptor for
computerized control
* DCS302A52
Interface between the central monitoring board and central
control units.
