List of Electrical and Functional Parts Si34-803
418 Appendix
Parts Name
Symbol
Model
Remark
FXMQ125MFV1 FXMQ200MFV1 FXMQ250MFV1
Remote
Controller
Wired Remote
Controller
BRC1C62
Option
Wireless Remote
Controller
—
Motors
Fan Motor M1F
AC200~240V 50Hz
1φ380W
Thermal protector 135°C : OFF 87°C : ON
Capacitor for Fan Motor
C1R
10µ F
400V×2
10µ F
400V
16µ F
400V
Solenoid
valve
Solenoid valve
(Hot gas)
Y1S
Body: VPV-603D
Coil: NEV-MOAJ532C1 AC220-240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-13 φ4 L=630
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-6 φ8 L=1250
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-2 φ6 L=1250
20kΩ (25°C)
Thermistor (for
discharge air)
R4T
ST8605-8 L=2000
20kΩ (25°C)
Others
Float switch S1L Option
Fuse F1U 250V 5A φ5.2
Transformer T1R TR22H21R8
