List of Electrical and Functional Parts Si34-803
416 Appendix
Parts Name
Symbol
Model
Remark
FXAQ
20MAVE
FXAQ
25MAVE
FXAQ
32MAVE
FXAQ
40MAVE
FXAQ
50MAVE
FXAQ
63MAVE
Remote
Controller
Wired Remote
Controller
BRC1C62
Option
Wireless Remote
Controller
BRC7E618
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ40W 1φ43W
Thermal protector 130°C : OFF 80°C : ON
Swing Motor M1S
MP24 [3SB40333-1]
AC200~240V
MSFBC20C21 [3SB40550-1]
AC200~240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-2 φ4 L400
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-2 φ8 L400
20kΩ (25°C)
Thermistor (for Heat
Exchanger)
R2T
ST8602-2 φ6 L400
20kΩ (25°C)
Others
Float Switch S1L
OPTION
Fuse F1U 250V 5A φ5.2
Parts Name
Symbol
Model
Remark
FXLQ
20MAVE
FXLQ
25MAVE
FXLQ
32MAVE
FXLQ
40MAVE
FXLQ
50MAVE
FXLQ
63MAVE
Remote
Controller
Wired Remote
Controller
BRC1C62
Option
Wireless Remote
Controller
BRC4C62
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ15W 1φ25W 1φ35W
Thermal protector 135°C : OFF 120°C : ON
Capacitor for Fan Motor
C1R 1.0µF-400V 0.5µF-400V 1.0µF-400V 1.5µF-400V 2.0µF-400V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-6 φ4 L1250
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-9 φ8 L2500
20kΩ (25°C)
Thermistor (for Heat
Exchanger)
R2T
ST8602A-9 φ6 L2500
20kΩ (25°C)
Others
Fuse F1U AC250V 5A
Transformer T1R TR22H21R8
