Model Selection Si34-803
10 General Information
Differences from Conventional Models
Item
Differences
Object New model (P(A) Model) Conventional model (P Model)
Compressor Connection of equalizer oil pipe
z NONE
(No particular changes in
terms of service)
z NONE
(No particular changes in
terms of service)
Workability
Equalizer oil pipe for multi-
outdoor-unit system
z NONE z NONE
Procedure for calculating
refrigerant refilling quantity
z Refilling quantity due to piping
length + Adjustment quantity
according to models of
outdoor units
z Refilling quantity due to piping
length + Adjustment quantity
according to models of
outdoor units
Optional accessories
Branch pipe for outdoor unit
connection
z Y branch
Type: BHFP22P100/151
z Y branch
Type: BHFP22P100/151
Refrigerant charge
Change of refrigerant amount
Refrigerant amount reduced to
less than 12 kg.
z Less than 12 kg
z Some of heat pump units
require refrigerant amount of
not less than 12 kg.
(Heat recovery units have
been designed for refrigerant
amount of less than 12 kg.)
