Specifications Si34-803
42 Specifications
Notes:
★1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference :
0m.
4 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as
RXYQ5PAYLE.
Model Name (Combination Unit)
YL(E)
RXYQ42PAYL(E) RXYQ44PAYL(E)
Model Name (Independent Unit) RXYQ8PAYL(E)+RXYQ16PAYL(E)+RXYQ18PAYL(E) RXYQ8PAYL(E)+RXYQ18PAYL(E)+RXYQ18PAYL(E)
Model Name (Combination Unit)
TL(E)
RXYQ42PTL(E) RXYQ44PTL(E)
Model Name (Independent Unit) RXYQ8PTL(E)+RXYQ16PTL(E)+RXYQ18PTL(E) RXYQ8PTL(E)+RXYQ18PTL(E)+RXYQ18PTL(E)
★1 Cooling Capacity (19.5°CWB)
kcal / h 101,000 104,000
Btu / h 399,000 413,000
kW 117 121
★
2 Cooling Capacity (19.0°CWB)
kW
116 120
★
3 Heating Capacity
kcal / h 114,000 119,000
Btu / h 450,000 471,000
kW 132 138
Casing Color
Without(E)
Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
With(E) Light Camel (2.5Y6.5/1.5) Light Camel (2.5Y6.5/1.5)
Dimensions: (H×W×D) mm (1680×930×765)+(1680×1240×765)+(1680×1240×765) (1680×930×765)+(1680×1240×765)+(1680×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston
Displacement
m³/h
YL(E) (16.90)+(12.84+12.52+12.52)+(12.84+12.52+12.52) (16.90)+(12.84+12.52+12.52)+(12.84+12.52+12.52)
TL(E) (16.90)+(12.84+12.52+12.52)+(12.84+12.52+12.52) (16.90)+(12.84+12.52+12.52)+(12.84+12.52+12.52)
Number of
Revolutions
r.p.m
YL(E) (7980)+(6060, 3450, 3450)+(6060, 3450, 3450) (7980)+(6060, 3450, 3450)+(6060, 3450, 3450)
TL(E) (7980)+(6060, 3450, 3450)+(6060, 3450, 3450) (7980)+(6060, 3450, 3450)+(6060, 3450, 3450)
Motor Output×Number
of Units
kW (4.5×1)+((2.7+4.5+4.5)×1)+((4.3+4.5+4.5)×1) (4.5×1)+((4.3+4.5+4.5)×1)+((4.3+4.5+4.5)×1)
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW (0.75×1)+(0.35×2)+(0.75×2) (0.75×1)+(0.75×2)+(0.75×2)
Air Flow Rate m³/min 180+233+239 180+239+239
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ19.1 (Brazing Connection) φ19.1 (Brazing Connection)
Gas Pipe mm φ41.3 (Brazing Connection) φ41.3 (Brazing Connection)
Product Mass (Machine Weight) kg 205+329+341 205+341+341
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 4~100 4~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 7.2+11.5+11.7 7.2+11.7+11.7
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No.
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
