Si34-803 Wiring Diagrams for Reference
Appendix 389
RXYQ34PA / 36PA / 38PA / 40PA / 42PA / 44PA / 46PA / 48PA / 50PA / 52PA / 54PAY1
RXYQ34PA / 36PA / 38PA / 40PA / 42PA / 44PA / 46PA / 48PA / 50PA / 52PA / 54PAYL
[UNIT 2]
POWER SUPPLY
[UNIT 3]
L
MAIN
SWITCH
L3N
MAIN
SWITCH
L1L2
POWER SUPPLY
L3 N
MAIN
SWITCH
L1L2
POWER SUPPLY
[UNIT 1]
FUSE
SWITCH
FUSE
SWITCH
FUSE
SWITCH
L2 L3L1 N L2 L3L1 N L2 L3L1 N
L2 L3L1 N
FUSE
SWITCH
N
POWER SUPPLY
L
MAIN
SWITCH
N
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
[UNIT 2] [UNIT 3][UNIT 1]
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
2 WIRES CABLE
(TRANSMISSION LINE)
OUTDOOR UNITS
OUTDOOR UNITS
INDOOR UNITS
INDOOR UNITS
2 WIRES CABLE
(POWER LINE)
2 WIRES CABLE
(POWER LINE)
LN
FUSE
SWITCH
2 WIRES CABLE
(POWER LINE)
LN
FUSE
SWITCH
2 WIRES CABLE
(POWER LINE)
LN
FUSE
SWITCH
2 WIRES CABLE
(POWER LINE)
2 WIRES CABLE
(POWER LINE)
2 WIRES CABLE
(POWER LINE)
2 WIRES CABLE
(POWER LINE)
LN
FUSE
SWITCH
LN
FUSE
SWITCH
LN
FUSE
SWITCH
2 WIRES CABLE
(POWER LINE)
LN
FUSE
SWITCH
2 WIRES CABLE
(POWER LINE)
LN
FUSE
SWITCH
Notes 1) All wiring, components and materials to be procured on the site must comply with
the applicable local and national codes.
2) Use copper conductors only.
3) As for details, see wiring diagram.
4) Install circuit breaker for safety.
5) All field wiring and components must be provided by licensed electrician.
6) Unit shall be grounded in compliance with the applicable local and national codes.
7) Wiring shown are general points-of-connection guides only and are not intended for or to
include all details for a specific installation.
8) Be sure to install the switch and the fuse to the power line of each equipment.
9) Install the main switch that can interrupt all the power souces in an integrated manner because
this system consists of the equipment utilizing the multiple power sources.
10) The capacity of UNIT1 must be larger than UNIT2 when the power source is connected in
series between the units.
11) If there exists the possibility of reversed phase, lose phase, momentary blackout or the power
goes on and off while the product is operating, attach a reversed phase protection circuit
locally.
Running the product in reversed phase may break the compressor and other parts.
When the power source is supplied to each
outdoor unit individually.
When the power source is connected in
series between the units.
3D052262D
