Specifications Si34-803
34 Specifications
Notes:
★1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level difference :
0m.
4 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as
RXYQ5PAYLE.
Model Name
60Hz
YL(E) RXYQ10PAYL(E) RXYQ12PAYL(E)
TL(E) RXYQ10PTL(E) RXYQ12PTL(E)
★1 Cooling Capacity (19.5°CWB)
kcal / h 24,300 29,000
Btu / h 96,200 115,000
kW 28.2 33.7
★
2 Cooling Capacity (19.0°CWB)
kW
28.0 33.5
★
3 Heating Capacity
kcal / h 27,100 32,300
Btu / h 107,000 128,000
kW 31.5 37.5
Casing Color
Without(E)
Ivory White (5Y7.5/1) Ivory White (5Y7.5/1)
With(E) Light Camel (2.5Y6.5/1.5) Light Camel (2.5Y6.5/1.5)
Dimensions: (H×W×D) mm 1680×930×765 1680×1240×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston
Displacement
m³/h
YL(E) 13.34+12.52 13.34+12.52
TL(E) 13.34+12.52 13.34+12.52
Number of
Revolutions
r.p.m
YL(E) 6300, 3450 6300, 3450
TL(E) 6300, 3450 6300, 3450
Motor Output×Number
of Units
kW (1.4+4.5)×1 (2.5+4.5)×1
Starting Method Soft Start Soft Start
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×1 0.35×2
Air Flow Rate m³/min 185 233
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ9.5 (Brazing Connection) φ12.7 (Brazing Connection)
Gas Pipe mm φ22.2 (Brazing Connection) φ28.6 (Brazing Connection)
Product Mass (Machine Weight) kg 249 285
Safety Devices
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
High Pressure Switch, Fan Driver Overload Protector, Over
Current Relay, Inverter Overload Protector
Defrost Method Deicer Deicer
Capacity Control % 14~100 14~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 7.9 9.5
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. 60Hz
YL(E) 4D061027 4D061028
TL(E) 4D060847A 4D060848A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
