Si34-803 List of Electrical and Functional Parts
Appendix 413
∗only for FXDQ20~63N(B)VE, FXDQ20~32PBVE (with Drain Pump Type)
Parts Name
Symbol
Model
Remark
FXKQ
25MAVE
FXKQ
32MAVE
FXKQ
40MAVE
FXKQ
63MAVE
Remote
Controller
Wired Remote
Controller
BRC1C62 Option
Wireless Remote
Controller
BRC4C61
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ15W 4P 1φ20W 4P 1φ45W 4P
Thermal Fuse 146°C
Thermal protector 120°C : OFF 105°C :
ON
Drain Pump M1P
AC 220-240V (50Hz)
PLD-12200DM
Thermal Fuse 145°C
Swing Motor M1S
MP35HCA [3P080801-1]
AC200~240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-13 φ4 L630
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-7 φ8 L1600
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-7 φ6 L1600
20kΩ (25°C)
Others
Float Switch S1L FS-0211B
Fuse F1U 250V 5A φ5.2
Transformer T1R TR22H21R8
Parts Name
Symbol
Model
Remark
FXDQ
20PBVE(T)
FXDQ
25PBVE(T)
FXDQ
32PBVE(T)
FXDQ
40NBVE(T)
FXDQ
50NBVE(T)
FXDQ
63NBVE(T)
Remote
Controller
Wired Remote
Controller
BRC1C62
Option
Wireless Remote
Controller
BRC4C65
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ62W 1φ130W
Thermal protector
130°C: OFF, 83°C: ON
Drain Pump M1P
AC220-240V (50Hz)
PLD-12230DM
Thermal Fuse 145°C
∗
Thermistors
Thermistor (Suction Air)
R1T
ST8601-1 φ4 L=250
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-4 φ8 L=800
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-4 φ6 L=800
20kΩ (25°C)
Others
Float Switch S1L FS-0211E ∗
Fuse F1U 250V 5A φ5.2
Transformer T1R TR22H21R8
